WA flexible electronics company and UW team win federal grant for manufacturing

Devin Mackenzie and the roll-to-roll printer at the Testbeds
WA flexible electronics company and UW team win federal grant for manufacturing

MicroConnex and UW professor J. Devin MacKenzie to develop new manufacturing process for printed flexible electronics at Washington Clean Energy Testbeds

June 28, 2018

J. Devin MacKenzie, technical director of the Washington Clean Energy Testbeds and Washington Research Foundation professor of clean energy, materials science and engineering, and mechanical engineering at UW, and MicroConnex, Inc., a Snoqualmie, Washington company that performs custom and low-volume flexible hybrid electronics (FHE) manufacturing for high-tech industries, have been awarded a $980,000 grant to solve a key need within the FHE technology base. Using the roll-to-roll printing capabilities of the Washington Clean Energy Testbeds, an open-access lab for fabricating and testing clean technologies, MicroConnex is developing the ability to fabricate novel copper-clad, high-density interconnects on flexible substrates at an industrially-relevant scale.

The research partnership is funded by NextFlex, a Department of Defense-backed consortium of academic institutions and industry partners focused on developing and manufacturing FHE in the United States. UW became one of 30 founding members of NextFlex in 2016.

“This collaboration leverages the Testbeds’ strengths in print-based roll-to-roll electronics and MicroConnex’s expertise in flex circuits and electroplating technology,” said MacKenzie. “We’re excited to create a lower-cost, greener alternative for flexible electronics in medical, defense, aviation, and consumer products.”

J. Devin MacKenzie
UW professor and Testbeds Technical Director J. Devin MacKenzie.

Flexible hybrid electronics represent a new class of electronics that are bendable, stretchable and highly robust — well matched to applications such as wearable electronics, on-body sensors, and electronics for extreme environments. Furthermore, FHE are both thin and lightweight ­— the total thickness of FHE circuitry can approach 25 micrometers, and replacing rigid electronics with FHE can result in a weight reduction of over 50%. The ability to manufacture FHE at scale using advanced printing techniques could revolutionize devices like compact wireless transmitters, actuators, and medical sensors. In addition, FHE technology could be the cornerstone of a new era of “smart” and conformable consumer products to better interface with the human body, further advancing the efficiency and interconnectedness of our world.

, WA flexible electronics company and UW team win federal grant for manufacturing

“We are operating at the cutting edge of flex manufacturing, where high-risk, high-reward R&D is needed to deliver cost-competitive, high-tech solutions,” said Steve Leith, vice president of engineering and technology at MicroConnex and UW chemical engineering alum (B.S. 1991; Ph.D. 1998). “As a small company, MicroConnex would be challenged to manage the financial and technical risk of a project of this scope without the Testbed facilities and UW as a partner. The Testbeds’ state-of-the-art equipment, staff expertise, and IP terms are ideal for this research partnership and our business needs.”

A man with a soul patch beard in a suit with no tie.
MicroConnex Vice President of Engineering and Technology Steve Leith.

MicroConnex’s new FHE manufacturing process is fully additive and eliminates many of the byproduct waste streams that result from conventional subtractive manufacturing techniques such as etching. Using the new process, a flexible substrate is first printed with a “seed” circuit pattern less than 300 nanometers thick, before the interconnects are built up along the pattern using electrodeposition. The project represents a significant advance for FHE manufacturing, moving away from typical subtractive circuitry fabrication processes while directly addressing fundamental challenges of circuit density, substrate flexibility, and manufacturing cost.

, WA flexible electronics company and UW team win federal grant for manufacturing
Close-up of the photopolymer plate (printing master) used for flexographic printing. (Felippe Pavinatto / Washington Clean Energy Testbeds)
, WA flexible electronics company and UW team win federal grant for manufacturing
Ultra-high resolution silver conducting traces printed via flexography. (Felippe Pavinatto / Washington Clean Energy Testbeds)
, WA flexible electronics company and UW team win federal grant for manufacturing
Ultra-high resolution silver conducting traces printed via flexography (Felippe Pavinatto / Washington Clean Energy Testbeds)

MacKenzie is an expert in printable and flexible electronic materials, having spent over 17 years in the field as a scientist, research leader, and seed-stage entrepreneur. His research team and MicroConnex have already begun their work on the NextFlex grant, with initial focus on demonstrating the ability to print high-resolution silver nanoparticle seed films on flexible polyimide substrates.  Subsequent research phases will develop the electrodeposition processes necessary to transform the seed film into a working circuit.  At the conclusion of the project, MicroConnex and the Testbeds will provide direct access to the developed technology to NextFlex members for both R&D and commercialization purposes.
